Hose Crimping Machine

Our product range includes a wide range of hydraulic hose crimping machine - c52, a50 manual hose crimping machine, hydraulic hose pipe crimping machine, hydraulic hose crimping machine - ex52, hydraulic hose crimping machine and ex76 hydraulic hose crimping machine.

H52 Hydraulic Hose Crimping Machine

Capacity 1/4 INCH 2 INCHES 4 wire hose

The most compact and easy to use machine in its range, H52 hydraulic hose crimping machine can be operated even by an unskilled operator. The dies are easy to change and designed for, maximum life and optimum and equal crimping on all eight segments. Large openings at front and rear enables bend type fittings to be crimped. Micrometer control system ensures perfect crimping with an accuracy of 0.05 mm. This machine has the capacity to crimp 2 inch 4 wire hoses.

Enquire Now
  • Additional Information
Crimping Capacity of 2 wire hose 2 inches
Crimping capacity of 4 wire hose 2 inches
Opening at Front side 155mm
Maximum inside opening without dies 125 mm
Opening at Rear end 150 mm
Maximum working pressure 315 kg/sq cms
Kilowatt of motor 3.75 KW (5 HP)
Voltage 415 V/ 220 V
Capacity of oil tank 50 Litres
Number of dies 10
Sizes of dies 15,19,23,26,30,34,38,45, 52,62
Noise level <75db
Weight of the machine 290 Kg
Dimensions of machine 720 x 470 x 790 mm
Dimensions of Export packing 800 x 550 x 860 mm
